1N5817, 1N5818, 1N5819
1N5817 and 1N5819 are Preferred Devices Axial Lead Rectifiers
This series employs the Schottky Barrier principle in a large area
metal−to−silicon power diode. State−of−the−art geometry features
chrome barrier metal, epitaxial construction with oxide passivation
and metal overlap contact. Ideally suited for use as rectifiers in
low−voltage, high−frequency inverters, free wheeling diodes, and
polarity protection diodes.
Features •
•
•
• http://onsemi.com SCHOTTKY BARRIER
RECTIFIERS
1.0 AMPERE
20, 30 and 40 VOLTS Extremely Low VF
Low Stored Charge, Majority Carrier Conduction
Low Power Loss/High Efficiency
These are Pb−Free Devices* Mechanical Characteristics: • Case: Epoxy, Molded
• Weight: 0.4 Gram (Approximately)
• Finish: All External Surfaces Corrosion Resistant and Terminal
Leads are Readily Solderable • Lead Temperature for Soldering Purposes:
•
• 260°C Max for 10 Seconds …
