Корпус Intersil M24.3 — Даташит

Plastic Packages for Integrated Circuits Package Outline Drawing
M24.3
24 LEAD WIDE BODY SMALL OUTLINE PLASTIC PACKAGE (SOIC)
Rev 2, 3/11 24
INDEX
AREA
7.60 (0.299)
7.40 (0.291) 10.65 (0.419)
10.00 (0.394) DETAIL "A"
1 2 3 TOP VIEW
1.27 (0.050)
0.40 (0.016) SEATING PLANE
2.65 (0.104)
2.35 (0.093) 15.60 (0.614)
15.20 (0.598) 0.75 (0.029)
x 45В°
0.25 (0.010) 0.30 (0.012)
0.10 (0.004) 1.27 (0.050)
0.51 (0.020)
0.33 (0.013) 8В°
0В°
0.32 (0.012)
0.23 (0.009) …
