BD135 -BD136
BD139 -BD140
Complementary low voltage transistor
Features
■ Products are pre-selected in DC current gain Application
■ General purpose
3 Description 1 SOT-32 These epitaxial planar transistors are mounted in
the SOT-32 plastic package. They are designed
for audio amplifiers and drivers utilizing
complementary or quasi-complementary circuits.
The NPN types are the BD135 and BD139, and
the complementary PNP types are the BD136
and BD140. Figure 1. Internal schematic diagram NPN Table 1. 2 PNP Device summary Order codes Marking BD135 BD135 BD135-16 BD135-16 BD136 BD136 BD136-16 BD136-16 BD139 BD139 BD139-10 BD139-10 BD139-16 BD139-16 BD140 BD140 BD140-10 BD140-10 BD140-16 BD140-16 May 2008 Rev 5 Package Packaging SOT-32 Tube 1/9
www.st.com 9 Contents BD135 -BD136 -BD139 -BD140 Contents
1 Electrical ratings 3 2 Electrical characteristics . 4
2.1 Electrical characteristics (curves) . 5 3 Package mechanical data . 6 4 Revision history 8 2/9 BD135 -BD136 -BD139 -BD140 1 Electrical ratings Electrical ratings
Table 2. Absolute maximum ratings
Value Symbol Parameter NPN PNP Unit BD135 BD139 BD136 BD140
VCBO Collector-base voltage (IE = 0) 45 80 -45 -80 V VCEO Collector-emitter voltage (IB = 0) 45 80 -45 -80 V VEBO Emitter-base voltage (IC = 0) IC
ICM
IB Collector current
Collector peak current
Base current 5 -5 V 1.5 -1.5 A 3 -3 A 0.5 -0.5 A PTOT Total dissipation at Tc ≤ 25 °C 12.5 W PTOT Total dissipation at Tamb ≤ 25 °C 1.25 W Tstg Storage temperature -65 to 150 °C 150 °C Max value Unit Rthj-case Thermal resistance junction-case 10 °C/W Rthj-amb Thermal resistance junction-ambient 100 °C/W Tj Table 3. …
