Datasheet Wago 816-103 — Даташит
2-проводная клеммная колодка для печатной платы; 1,5 мм²; Шаг контактов 5 мм; 3-полюсный; Зажим Push-in CAGE CLAMP
2-CONDUCTOR PCB TERMINAL BLOCK; | |||
| 816-103 Wago | 600 ₽ | ||
| R81.61.03 | по запросу | ||
| 816-103 Wago | по запросу | ||
| 816103C Filtran | по запросу | ||
Купить 816-103 на РадиоЛоцман.Цены
Параметры
| Actuation type | Operating tool |
| Clamping spring material | Chrome nickel spring steel (CrNi) |
| Цвет | gray |
| Conductor entry angle to the PCB | 45 ° |
| Connection technology | Push-in CAGE CLAMP® |
| Contact material | Copper alloy |
| Contact plating | tin-plated |
| Country of origin | CH |
| Габариты: глубина | 17 mm / 0.669 inch |
| Drilled hole diameter (tolerance) | 1.1(+ 0.1) мм |
| Fine-stranded conductor | 0.2 … 1.5 mm² / 24 … 16 AWG |
| Fine-stranded conductor with ferrule with plastic collar | 0.2 … 1 mm² |
| Fine-stranded conductor with ferrule without plastic collar | 0.2 … 1.5 mm² |
| Fire load | 0.074 MJ |
| Flammability class per UL94 | V0 |
| GTIN | 4045454732066 |
| Height | 20.1 mm / 0.791 inch |
| Height from the surface | 16.6 mm / 0.654 inch |
| Insulating material | Polyamide 66 (PA 66) |
| Legend (ratings) | (III / 2) ≙ Overvoltage category III / Pollution degree 2 |
| Limit temperature range | -60 … +105 °C |
| Material group | I |
| Number of Poles | 3 |
| Number of connection types | 1 |
| Number of levels | 2 |
| Number of solder pins per potential | 1 |
| PCB contact | THT |
| Pin spacing | 5 mm (0.197 inch) |
| Product Group | 4 (Printed Circuit) |
| Rated current | 14 A |
| Rated impulse voltage (II / 2) | 4 kV |
| Rated impulse voltage (III / 2) | 4 kV |
| Rated impulse voltage (III / 3) | 4 kV |
| Rated voltage (II / 2) | 630 В |
| Rated voltage (III / 2) | 320 В |
| Rated voltage (III / 3) | 320 В |
| Solder pin arrangement | over the entire terminal strip, in line |
| Solder pin dimensions | 0.8 x 0.5 mm |
| Solder pin length | 3.5 мм |
| Solid conductor | 0.2 … 1.5 mm² / 24 … 16 AWG |
| Strip length | 9 … 10 mm / 0.35 … 0.39 Inch |
| Total number of connection points | 6 |
| Total number of potentials | 3 |
| Вес | 3.75 г |
| Ширина | 16.5 mm / 0.65 inch |
Модельный ряд
Серия: 816 (11)
Классификация производителя
- PCB Interconnect
Варианты написания:
816103, 816 103
