LM3303/LM3403
Quad Operational Amplifiers
Y General Description
The LM3303 and LM3403 are monolithic quad operational
amplifiers consisting of four independent high gain, internally frequency compensated, operational amplifiers designed
to operate from a single power supply or dual power supplies over a wide range of voltages. The common mode
input range includes the negative supply, thereby eliminating the necessity for external biasing components in many
applications. Features
Y Y Y Y
Y
Y
Y Applications
Y Input common mode voltage range includes ground or
negative supply
Output voltage can swing to ground or negative supply Connection Diagram Four internally compensated operational amplifiers in a
single package
Wide power supply range single supply of 3.0V to 36V
dual supply of g 1.5V to g 18V
Class AB output stage for minimal crossover distortion
Short circuit protected outputs
High open loop gain 200k
LM741 operational amplifier type performance Y Filters
Voltage controlled oscillators Order Information 14-Lead DIP and SO-14 Package TL/H/10064 – 1 Device …
