Revised January 1999 MM74C925 • MM74C926 • MM74C927 • MM74C928
4-Digit Counters with Multiplexed
7-Segment Output Drivers
General Description
The MM74C925, MM74C926, MM74C927 and MM74C928
CMOS counters consist of a 4-digit counter, an internal output latch, NPN output sourcing drivers for a 7-segment display, and an internal multiplexing circuitry with four
multiplexing outputs. The multiplexing circuit has its own
free-running oscillator, and requires no external clock. The
counters advance on negative edge of clock. A HIGH signal on the Reset input will reset the counter to zero, and
reset the carry-out LOW. A LOW signal on the Latch
Enable input will latch the number in the counters into the
internal output latches. A HIGH signal on Display Select
input will select the number in the counter to be displayed;
a LOW level signal on the Display Select will select the
number in the output latch to be displayed.
The MM74C925 is a 4-decade counter and has Latch
Enable, Clock and Reset inputs.
The MM74C926 is like the MM74C925 except that it has a
display select and a carry-out used for cascading counters.
The carry-out signal goes HIGH at 6000, goes back LOW
at 0000.
The MM74C927 is like the MM74C926 except the second
most significant digit divides by 6 rather than 10. Thus, if …
