AD8605/AD8606/AD8608 Data Sheet 5.10 5.00 4.90 14 8 4.50 4.40 6.40 BSC 4.30 1 7 PIN 1 0.65 BSC 1.05 1.20 1.00 MAX 0.20 0.80 0.09 0.75 0.15 8° 0.60 SEATING 0.05 0° 0.30 0.45 PLANE COPLANARITY 0.19 0.10 A COMPLIANT TO JEDEC STANDARDS MO-153-AB-1 061908-
Figure 66. 14-Lead Thin Shrink Small Outline Package [TSSOP] (RU-14) Dimensions shown in millimeters and (inches)
ORDERING GUIDE Model1 Temperature Range Package Description Package Option Marking Code
AD8605ACBZ-REEL7 −40°C to +125°C 5-Ball WLCSP CB-5-1 A1J AD8605ARTZ-R2 −40°C to +125°C 5-Lead SOT-23 RJ-5 B3A# AD8605ARTZ-REEL −40°C to +125°C 5-Lead SOT-23 RJ-5 B3A# AD8605ARTZ-REEL7 −40°C to +125°C 5-Lead SOT-23 RJ-5 B3A# AD8606ARM-REEL −40°C to +125°C 8-Lead MSOP RM-8 B6A AD8606ARMZ-R7 −40°C to +125°C 8-Lead MSOP RM-8 B6A# AD8606ARMZ-REEL −40°C to +125°C 8-Lead MSOP RM-8 B6A# AD8606ARZ −40°C to +125°C 8-Lead SOIC_N R-8 AD8606ARZ-REEL −40°C to +125°C 8-Lead SOIC_N R-8 AD8606ARZ-REEL7 −40°C to +125°C 8-Lead SOIC_N R-8 AD8606ACBZ-REEL7 −40°C to +125°C 8-Ball WLCSP CB-8-1 B6A# AD8608ARZ −40°C to +125°C 14-Lead SOIC_N R-14 AD8608ARZ-REEL −40°C to +125°C 14-Lead SOIC_N R-14 AD8608ARZ-REEL7 −40°C to +125°C 14-Lead SOIC_N R-14 AD8608ARUZ −40°C to +125°C 14-Lead TSSOP RU-14 AD8608ARUZ-REEL −40°C to +125°C 14-Lead TSSOP RU-14 1 Z = RoHS Compliant Part, # denotes RoHS compliant product (except for CB-5-1) may be top or bottom marked.
