BRT11, BRT12, BRT13www.vishay.com Vishay Semiconductors
Optocoupler, Phototriac Output, Non-Zero Crossing FEATURES• ITRMS = 300 mA • High static dV/dt < 10 000 V/μs • Electrically insulated between input and output A 1 6 MT2 circuit • Microcomputer compatible - very low trigger C 2 5 NC current • Trigger current NC 3 4 MT1 - (IFT < 1.2 mA) BRT12
F- (IFT < 2 mA) BRT11
H, BRT12
H, BRT13
H- (IFT < 3 mA) BRT12
M, BRT13
M• Non-zero voltage detectors high input sensitivity 23128 • Material categorization: for definitions of compliance please see www.vishay.com/doc?99912
LINKS TO ADDITIONAL RESOURCES APPLICATIONS• Industrial controls
Related• Office equipment
Documents• Consumer appliances
DESCRIPTIONThe BRT11, BRT12, and BRT13 product family consists of
AGENCY APPROVALSAC optocouplers non-zero voltage detectors consisting of • UL / cUL 1577 two electrically insulated lateral power ICs which integrate a • DIN EN 60747-5-5 (VDE 0884-5), available with option 1 thyristor system, a photo detector and noise suppression at the output and an IR GaAs diode input.
ORDERING INFORMATIONDIP-6 Option 6
B R T 1 # x - X 0 # # TPART NUMBER PACKAGE OPTION TAPE 7.62 mm 10.16 mm AND Option 7 Option 9 REEL > 0.7 mm > 0.1 mm
AGENCY VDRM (V) CERTIFIED / PACKAGE≤
400≤
600≤
800 UL IFT = 2 mA IFT = 1.2 mA IFT = 2 mA IFT = 3 mA IFT = 2 mADIP-6 BRT11H BRT12F BRT12H BRT12M BRT13H DIP-6, 400 mil, option 6 - - BRT12H-X006 - BRT13H-X006 SMD-6, option 7 - BRT12F-X007T BRT12H-X007T - BRT13H-X007T (1) SMD-6, option 9 - - BRT12H-X009T - BRT13H-X009T
UL, VDE IFT = 2 mA IFT = 1.2 mA IFT = 2 mA IFT = 3 mA IFT = 2 mADIP-6 - - BRT12H-X001 BRT12M-X001 - DIP-6, 400 mil, option 6 - - BRT12H-X016 - - SMD-6, option 7 - - - - BRT13H-X017T
Note(1) Also available in tube, do not put T on the end Rev. 1.8, 14-Jul-2021
