80 V, 1 A PNP Medium Power Transistors
Выписка из документа
BCP53; BCX53; BC53PA
80 V, 1 A PNP medium power transistors
Rev. 9 — 19 October 2011 Product data sheet 1. Product profile
1.1 General description
PNP medium power transistor series in Surface-Mounted Device (SMD) plastic packages.
Table 1. Product overview Type number[1] Package
Nexperia JEITA JEDEC BCP53 SOT223 SC-73 -BCP56 BCX53 SOT89 SC-62 TO-243 BCX56 BC53PA SOT1061 -BC56PA [1] NPN complement Valid for all available selection groups. 1.2 Features and benefits High current
Three current gain selections
High power dissipation capability
Exposed heatsink for excellent thermal and electrical conductivity (SOT89, SOT1061)
Leadless very small SMD plastic package with medium power capability (SOT1061)
AEC-Q101 qualified 1.3 Applications Linear voltage regulators
High-side switches
Battery-driven devices
Power management
MOSFET drivers
Amplifiers 1.4 Quick reference data
Table 2. Quick reference data Symbol Parameter Conditions Min Typ Max Unit VCEO collector-emitter voltage open base -80 V IC collector current -1 A ICM peak collector current -2 A single pulse; tp 1 ms BCP53; BCX53; BC53PA Nexperia 80 V, 1 A PNP medium power transistors Table 2. Quick reference data …continued Symbol Parameter Conditions Min Typ Max hFE DC current gain VCE = 2 V;
IC = 150 mA 63 -250 hFE selection -10 VCE = 2 V;
IC = 150 mA 63 -160 hFE selection -16 VCE = 2 V;
IC = 150 mA 100 -250 Unit 2. Pinning information
Table 3.
Pin Pinning …
